PE 1623 PV
Brief description: hoods, sockets, 2 poles + PE, 16 (A.C.), >50V, 2 green, IP44
Technical details
| Product description | |
| Model | sockets |
| Version | PLUSO, plugs and socket-outlets |
| Series | PE...PV |
| Product type | hoods |
| Variant | screw terminal connections |
| Family | plugs and socket-outlets |
| N. of poles | 2 poles +  |
| Clock position | 2
|
| Technical data | |
| Current | 16 A (A.C.) |
| Voltage | > 50 V |
| Frequency | > 300 ÷ 500 Hz. |
| Operating temperature range (min, max) | -40°C … +125°C |
| Material | thermoplastic |
| IP degree of protection | IP44 |
| Further technical details | |
| Weight | 120,00 g |
| Approvals / Standards | |
| Reference standard | EN 60309-1 and -2 |
| Quality mark | EAC |
| General ordering information | |
| EAN13 code | 8015747063258 |
| Packaging Information | |
| Sub-packaging length | 175,00 mm |
| Sub-packaging height | 100,00 mm |
| Sub-packaging width | 235,00 mm |
| Sub-packaging weight | 1,20 kg |
| Sub-packaging volume | 4,11 dm³ |
| Sub-packaging description | Carton Box |
| Sub-packaging quantity | 10 Pcs |
| Sub-packaging EAN barcode | 8015747063265 |
