CXF 6/6
Brief description: female insert, 6 poles + PE, crimp connections, 100A 690V, (6 poles (16A max - 400V)), 8kV, 3, for female contacts 100A and 16A, size "104.27", CLASS insert series
Technical details
| Product description | |
| Model | female insert |
| Version | crimp connections |
| Series | CX |
| Product type | for female contacts 100A and 16A |
| Family | CLASS inserts |
| Size | size "104.27" |
| N. of poles | 6 poles + |
| Auxiliary poles | 6 poles (16A max - 400V) |
| Technical data | |
| Current | 100 A (A.C. and D.C.) |
| Voltage | 690 V |
| Rated impulse withstand voltage | 8kV |
| Pollution degree | 3 |
| Operating temperature range (min, max) | -40°C … +125°C |
| Mating cycles | ≥ 500 |
| IP degree of protection | IP20 without enclosure; IP65/IP66/IP67/IP68 with enclosure |
| PE connection type | Screw |
| PE terminal stripping length | 100A: 15mm; 16A: 7,5mm |
| Tightening torque for PE connection | M4: 1,2 Nm, 10,6 lb,in (Ph2 or 1,0x5,5mm ) |
| Further technical details | |
| Characteristics according to EN 61984 | 100A 690V 8kV 3 (aux: 16A 400V 6kV 3) |
| Insulation resistance | ≥ 10 GΩ |
| Contact resistance | ≤ 0,3 mΩ (100A); ≤ 1 mΩ (16A) |
| Rated voltage according to UL/CSA | 600V |
| UL 94 flammability rating | V-0 |
| Main contats stripping length | 100A: 15mm; 16A: 7,5mm |
| Tightening torque for fixing screws | M3: 0.5 Nm; 4.4 lb.in (Ph1 or 0.8x4 mm) |
| Weight | 116,50 g |
| Approvals / Standards | |
| Reference standard | EN 61984 (2001-11) |
| Quality mark | , EAC |
| Conformity | CQC, CE |
| General ordering information | |
| EAN13 code | 8015747192170 |
| Tariff number | 85369095 |
| Country of origin | Made in EU (IT) |
| ETIM classification | EC000438 |
| Packaging Information | |
| Packaging length | 130,00 mm |
| Packaging height | 145,00 mm |
| Packaging width | 300,00 mm |
| Packaging weight | 1,32 kg |
| Packaging volume | 5,66 dm³ |
| Packaging description | Carton box |
| Packaging quantity | 10 Pcs |
| Packaging EAN code | 8015747192187 |
| Sub-packaging weight | 0,13 kg |
| Sub-packaging description | Plastic bag |
| Sub-packaging quantity | 1 Pcs |
| Sub-packaging EAN barcode | 8015747192194 |
